MILLING CHUCK (CAT) |
 |
| MILLING CHUCK (CAT) |
| TAPER No. | MODEL No. | d | L | D | EDP No. |
| 40 | CAT40-C3/4-4.13 | 0.750 | 4.13 | 2.050 | LK010 |
| CAT40-C1"-4.13 | 1.000 | 4.13 | 2.360 | LK014 | |
| CAT40-C1 1/4-4.13 | 1.250 | 4.13 | 2.835 | LK017 | |
| 50 | CAT50-C3/4-4.13 | 0.750 | 4.13 | 2.050 | LL010 |
| CAT50-C1"-4.13 | 1.000 | 4.13 | 2.360 | LL014 | |
| CAT50-C1 1/4-4.13 | 1.250 | 4.13 | 2.835 | LL017 |
